Contour measurement
Capturing profiles and evaluating them to standard, in the temperature-controlled measuring room. For example thread, sealing and functional contours.
Skip to content
Measurement method
Describe your measurement task
Performance data
Frequently asked
What we measure contours for
When the profile decides the function.
Capturing profiles and contours and evaluating them to standard
Thread, sealing and functional contours
Characteristics per drawing and ISO GPS
Stylus method for function-critical contours
Characteristics
Radii, angles, steps and profile traces, captured exactly and evaluated to standard
Measuring range
250 × 320 mm
Sensors
interchangeable stylus arms with double tip, also for hard-to-reach contours
Typical contours
thread profiles, sealing seats, chamfers, groove forms, free-form contours
Official measurement service provider
of Mitutoyo Switzerland
ISO 9001:2015 certified
Certified quality management system
ISO GPS standardisation
Member of Swissmem NK1, ISO/TC 213
What customers ask about contour measurement
Which characteristics do you measure in the contour section?
Radii, angles, chamfers, groove forms, thread profiles and free-form contours in section, as a comparison against the nominal contour from the drawing or CAD.
Are the instruments calibrated?
Yes. The stylus instruments are calibrated with traceable standards; on request, we enclose the evidence with your documentation. What a calibration proves (German) →
Describe your measurement task.
Describe the contour and the characteristic. Quotes are effort-based and transparent.
Prefer to talk first?
A 30-minute technical call about your drawing or measurement task. Free of charge, in English or German.
Pick a time →
Project enquiry
Send us your measurement task by email
Briefly describe the part and the contour to be inspected, and attach the drawing — excerpts are fine. An NDA before the first file is available on request. You normally receive a reply within one working day, in English if you prefer.
Write to info@csl-imt.ch →
Or use the project form on the German contact page — it accepts uploads and an NDA option.
